The details behind the woodgrain.

Standards, downloads, profile drawings and installation guidance for specifiers, builders, installers and inspectors.

Downloads

Documents

Product data sheetPDF · 2 pages · Element LineCladding & soffit installation guidePDF · 8 pages · Tongue-and-groove systemCAD profile drawingsPanels, clips & trims · on request

Always confirm you are using the most current version. Product specifications are subject to change without notice.

Product certifications

Standards & testing

CAN/ULC S135Non-combustibility
CAN/ULC S102Flame spread rating and smoke developed classification
CGSB 93.2-M91Prefinished aluminum siding, soffits and fascia
CGSB 93.1-M85Prefinished aluminum sheet, coating performance
ASTM D4214Coating performance: no chalking after 2,000 hours
Impact / hailExceeds standard aluminum siding

Material: Powder-coated 6063-T5 extruded aluminum.

Profiles

Two reveals.
One precise joint.

AFX-TG43D render of the AFX 4″ profile tongue-and-groove aluminum panel4″ profile · 101.60 mm reveal

AFX Element Line

Element 4″ panel

Tongue-and-groove cladding and soffit panel with a 101.60 mm visible reveal, installed on concealed GripClips and finished with matching trims.

Product code
AFX-TG4
Visible reveal
101.60 mm
Overall width
116.75 mm
Weight
0.602 kg/m
Length
16 ft · 4.88 m
Nominal wall
1.60 mm
Price this profile Data sheet
Dimensioned section drawing of the 4″ profile panel: 116.75 mm overall, 101.60 mm reveal
SSP-040 · Rev B · Section viewAll tolerances per BS EN 755-9
Dimensioned CAD detail A of the AFX panel leading edge at 5:1 scale
Detail A · Leading edgeScale 5:1
Dimensioned CAD detail B of the AFX panel interlocking edge at 5:1 scale
Detail B · Interlock edgeScale 5:1

Both profiles share the same edge geometry, so the 4″ and 6″ panels lock together the same way.Request CAD drawings

Installation at a glance

Built for a clean, efficient install.

A summary of the installation guide. We strongly recommend installation by experienced professionals, and all parties should review the full guide before starting work.

  1. 01SSS-003 · SSC-014

    Starter strip & GripClips

    TrueLine starter strip at the lowest point of the finished wall, fastened through the flange at every second clip.

  2. 02TCA-009 · TCB-016

    DuoFit corner bases

    Install all corner bases before panels. The same two extrusions form inside and outside corners.

  3. 03TJA-009

    J-trim, where required

    Vertical termination where a panel run does not end at a corner.

  4. 04TFA-014

    Twin cap trim base

    Finishing base between corner bases and J-trim, aligned with adjacent vertical trims.

  5. 05AFX-TG4 · TG6

    Element panels

    Install bottom-to-top, engaging each tongue-and-groove joint over the concealed clips.

  6. 06TFB-014

    Corner & trim caps

    Cut caps to height and snap onto the installed bases. Non-structural, they allow for linear expansion.

Plan the layout

  • Confirm layout, alignment, terminations and expansion breaks before installation.
  • Substrates must be straight, true, dry and free of debris.
  • Do not install directly over pressure-treated substrates without an approved protective barrier.

Fastening

  • Minimum two AFX GripClips (SSC-014) per panel.
  • Clip spacing: 32″ on centre for normal wind loads, 16″ for high-wind conditions.
  • #10 pan-head stainless steel, or otherwise exterior-rated, fasteners.
  • Consult the authority having jurisdiction or project engineer for project-specific requirements.

Expansion

  • Leave a ¼″ gap at both panel ends where concealed by trim.
  • Runs of 0–16 ft: ¼″ gap. Runs of 16–32 ft: ½″ gap.
  • Over 32 ft, use J-trim to create expansion breaks.
  • Leave ⅛″ between adjoining vertical trim components.

Cutting & handling

  • Compound mitre saw or table saw with a 60–80T carbide blade for non-ferrous metal.
  • Wear hearing and eye protection. Secure material and remove sharp edges after cutting.
  • Handle with care to protect the coating from scratches.
  • Tap tongue-and-groove joints together with a rubber mallet for full engagement.
Corner overhang clad in AFX woodgrain aluminum panels

Care & cleaning

Mild detergent, water, soft brush. That’s it.

Never use abrasive or aggressive cleaners on AFX products. No staining, sealing or repainting required.

Download the full guide Ask a technical question

This summary is for general information only. Installation methods may vary with building design, environmental conditions and applicable building codes. The installer, contractor, architect or project engineer is responsible for ensuring compliance with local codes, regulations and project specifications. Refer to the full installation guide for details.
